AWS Instances for Aerospike Clusters
How I select the optimal AWS instance type for running Aerospike
One of the most common conversations I have when providing consulting services for Aerospike customers running on AWS is about how to select the optimal AWS instance type.
Which instance provides the lowest latency?
Do I need a “storage optimized” instance type?
Should I use EBS?
Can I use a cheaper instance type?
When it comes to running production Aerospike workloads at scale on AWS I generally only look at a this short list of instance families:
i3en instances: All the things! Big and fast with lots of storage
i3 instances: Lots of storage at a low cost
r5/r5d instances: Fast with lowest cost per GB of DRAM
c5d instances: Very fast and low cost per vCPU
m5d instances: Low-latency all-rounder
So let’s look closer at what I consider when selecting AWS instance types for Aerospike customers and then what each of these instance families is good at and where it might fall short.
Instance Type Considerations
None of the technical considerations matter without cost. If price were no object I’d just say run Aerospike on a big ol’ cluster consisting of the beefy i3en instances and be done with it.
But alas, we live in the real world…
Storage
The first consideration for Aerospike on AWS is storage. Aerospike’s Hybrid Storage configured to use SSD/Flash is going to be used in the vast majority of use cases.
This means I want fast, consistent, and reliable NVMe SSD storage. Amazon’s network-attached storage, Elastic Block Store (EBS), does not meet that need. EBS is fantastic for many storage needs, but it is not fast, consistent, or reliable when milliseconds matter. No, what I need is Amazon’s SSD instance store volumes.
But, not all instance store volumes are equal. Aerospike has certified the throughput of AWS SSD volumes for various instance families. This provides a good baseline for the relative performance expected from any given instance type.
As a general rule I try to avoid instance sizes that don’t make use of a full sized SSD for a given family. That means that I try not to go smaller than the smallest instance type within a family that has the same size SSD as the largest in that family (half-size instances and above). This is to avoid sharing the physical SSD with other tenants on the underlying AWS host.
Memory
When Aerospike’s Hybrid Storage is configured to store data in memory then the RAM is obviously the primary factor in the instance’s storage capacity. When configured to store primary indexes in memory it’s still a key factor, but, with some nuance.
Aerospike’s primary indexes are a fixed size (64 bytes) per object. That means that if I am storing a large amount of small objects then I need a higher memory-to-disk ratio than if I have fewer large objects.
I also want to condider optional features than can leverage RAM such as read page cache and secondary index.
Network
The oft-overlooked network capacity is very important in cloud environments.
Obviously the network throughput and latency is an important consideration. However, there is also clustering and the application’s usage pattern to consider. Does the application have an aggressive SLA? How will it behave when the network is down? What about when the network is slow or dropping packets?
So a more consistent and reliable network results in a more stable cluster. Sure, Aerospike will automatically handle nodes leaving the cluster due to a flakey network, however, that self-healing means replicating data and replicating data means spending money on data transfer.
This means instance size matters in addition to the type. When I’m looking at the AWS instance type documentation I’m paying special attention to the “Networking Performance” column. When the value is “up to X” then it’s a bursty shared network allocation and the noisy neighbor effect will be more pronounced.
CPU
I avoid the “burstable” general-purpose instance families like the t2/ t3 instances for production workloads. It's too risky to be able to accidentally push up above the baseline performance and have unexpected disruptions when CPU credits run dry from bursting.
But beyond that, CPU is rarely a primary consideration in selecting the right instance type. As instance types are sized up to accomodate storage, memory, or network, I more often find CPU to be under-utilized.
This is an opportunity for optimization as there are a number of optional features that can take advantage of under-utilized CPU:
TLS encryption in transit and encryption at rest can improve security (IMHO encryption should be the rule, not the exception).
Storage compression can reduce overall storage capacity which means more cost savings.
Client-server compression on the wire can save money on AWS ingress/egress costs.
Taking advantage of the rich set of APIs available for complex-data types (CDTs) can optimize for both cost and performance by offloading some of the data manipulation to the Aerospike nodes.
So, for use cases that are not using these features I consider whether or not there is an opportunity to make use of more CPU to optimize for cost, performance, or both. And then of course the inverse is also true. I make sure to consider CPU for use cases that are using these features.
Instance Type Selection
The storage optimized instances are the obvious contender. Both the older i3 and the shiny new i3en instance families are viable. But, the compute optimized c5 instances and the memory optimized r5 are great options depending on the use case, and the m5 instances are a solid choice from the general purpose category.
i3en Instances
When talking about storage optimized AWS instances the i3en is the big dog. I was pretty excited about these when AWS announced them just last year.
First, they have a huge amount of SSD capacity at the lowest cost per GB. The largest i3en.24xlarge weighs in at whopping 8 x 7.5 TB SSD volumes for 60 TB of storage per instance at ~$1.58 per GB per year¹.
Second, they have pretty fast drives. We’ve clocked one of these SSD drives at 162k TPS. When compared to the i3 at 33k TPS that's a significant improvement!
When compared with the older i3 instances, these instances have more SSD storage at a lower cost per GB, more SSD throughput, more CPU, more network, and more RAM. So... moar!
The down sides are that being relatively new they may not be available in all regions and they have a higher cost per GB of RAM than memory optimized r5 instances.
I like the i3en instances for low-latency workloads storing large amounts of data with a memory-to-disk ratio on the i3en instances that results in a storage-bound cluster. In other words, when the number of instances is selected based on how much data needs to be stored and the indexes will fit into the available memory.
I also like the i3en instances for a configuration in which indexes are stored on the SSD as well as the data ("all flash"). This allows for HUGE amounts of data (think hundreds of TB and beyond) without breaking the bank on DRAM.
For the best performance the SSD disks should be over-provisioned 20%.
i3 Instances
Before the i3en instances hit the scene these were the kings of SSD capacity. The largest i3.16xlarge instance has 8 x 1.9 TB SSD volumes. That's 15.2 TB of storage per instance at ~$2.88 per GB per year¹.
They also have a very good cost per GB of RAM.
The down side is the drives are substantially slower and they have less vCPU than all the other instance families being considered. In short, they are the slowest.
I like the i3 instances when i3en is not available and storing large amounts of data. With a fairly low cost per GB of RAM and a fairly low cost per GB of SSD storage, I also like the i3 as a cost-effective all-rounder for lower throughput workloads.
For the best performance the SSD disks should be over-provisioned 20%.
r5 and r5d Instances
The memory optimized r5 instances provide the best cost per GB of RAM which makes them the ideal for when Aerospike is configured as an in-memory database. The largest r5.24xlarge instances have 768 GB of RAM per instance at ~$78.84 per GB per year.
However, the r5d variant also adds 4 x 900 GB SSD volumes for a total of 3.6 TB per instance. These are fairly fast SSD drives which we've clocked at 138k TPS.
The down side is that the r5d variant has the highest cost per GB of SSD storage of all the instance types considered here.
I like the r5 instances for running Aerospike as an in-memory database and I like the r5d instances for low-latency use cases where the memory-to-disk ratio results in a memory-bound cluster.
c5d Instances
The compute optimized c5d instances are all about speed. When latency is the be-all/end-all these are the front runner. They have the most powerful CPUs and the SSD volumes are very fast.
The down sides are that they have the highest cost per GB of RAM by a wide margin and max out at 192 GB RAM per instance.
I like the c5d instances when the use case is very latency sensitive, is making use of CPU heavy features of Aerospike (encryption, compression, CDTs, etc.), and the memory-to-disk ratio does not result in a memory-bound cluster.
Instance Comparison
To do an objective comparison of these instance types based on a specific workload with specific performance requirements, I refer to the following resources:
The following table compares the maximum size instance types for each family on my short list. The cost is broken down into annual cost per some unit of capacity. This makes it easy to make a first pass at which instance familiy is going to be a good fit for a specific workload.
For example:
A high-throughput workload without a small amount of data is likely to be most cost effective on c5d instances as they have a low cost per 1k TPS.
A high-throughput workload with a very large amount of data is likely to be most cost effective on i3en instances as they have a low cost per 1k TPS but also have a lot of SSD storage.
A high-throughput workload with a lot of small objects, and thus a high memory-to-disk ratio, is likely to be most cost effective on r5d instances as they have a low cost per GB of DRAM.
A low-throughput workload with a lot of data with a moderate/high number of objects is likely to be most cost effective on i3 instances as they have both low cost per GB of DRAM as well as low cost per GB of SSD storage.
¹ Cost estimates based on largest instance type in family using the full list pricing for on-demand instances in us-east-1 as of September 2020
² Per-instance TPS based on a single drive multiplied by total drives per instance. See details and caveats at Cloud-Based Flash ACT results
Scaling Strategy (Instance Size vs. Cluster Size)
The instance type selection pointed out that the smaller end of the sizes within an instance family have bursty network and shared SSD controllers due to the amount of other tenants on the host. What this amounts to is these instance sizes will have more variability in their performance characteristics.
For smaller workloads there must be a trade off between larger instance sizes and larger cluster sizes. The consideration here is about having enough instances in the cluster to spread the workload out which lessens the impact of single instance maintenance or failure versus minimizing the variability of the performance. On the other end of the spectrum as the cluster grows more nodes can mean longer maintenance for rolling updates and larger instances mean slower cold restarts as indexes are being rebuilt.
There is no hard and fast rule here and these considerations must be taken in context of each organization’s budget and operational parameters, however, the approach I take for production clusters is loosely:
Prefer a cluster size of 2x availability zones and don’t go less than 1x
Prefer instance sizes with fixed network performance and don’t go less than 4 vCPU
So that means if I’m designing a production cluster in 3 zones based on the r5d family the smallest cluster I would recommend is 3x r5d.xlarge (4vCPU).
The scaling strategy would be to scale out to 6x r5d.xlarge to get to 2x zones after which it would then scale up until it gets to the r5d.8xlarge which have the fixed network.
However, if the workload is latency sensitive and the variability of the small instances is a concern then the scaling strategy would insted be to scale up from the minimum cluster size of 3 until it gets to 3x r5d.8xlarge where it has the fixed network. Then it would start scaling out to 6x r5d.8xlarge.
Once reaching the point of 6x r5d.8xlarge scaling up to the r5d.12xlarge would be the next step to get to the full-size SSD (not shared). After that the decisions to continue to scale up vs. out are largely dependent on the opertational parameters that best suite the organization.
Conclusion
The art of selecting the right instance type is about optimizing the cost to performance ratio.
One of the beautiful things about running Aerospike in the cloud is that you don’t have to get it perfect on day one. You can start with a conservative approach in which you leave room for the application usage patterns to evolve and stabilize before right-sizing based on real-world production metrics. Remember, with Aerospike you can always do rolling updates, with zero downtime, to switch between instance sizes and types or do A/B testing.
